iFlight Nazgul DC5 ECO V1.1 DJI O4 6S HD 2.4GHz ELRS

iFlight Nazgul DC5 ECO V1.1 DJI O4 6S HD 2.4GHz ELRS

Product description

The Nazgul DC5 ECO is a 5-inch freestyle drone that redefines performance and value for money. Equipped with the DJI O4 Digital HD system, it delivers razor-sharp, propeller-free 4K video even in low light conditions. The robust carbon frame and aluminum camera mount guarantee durability without sacrificing lightness. The pre-installed GoPro mount makes the drone even more versatile.

Thanks to the BLITZ ATF435 flight controller and the powerful BLITZ E55S ESC, the Nazgul DC5 ECO offers a reliable and dynamic flying experience. With a maximum speed of 190 km/h and an optimized DeadCat design, this drone is perfect for FPV pilots looking for performance and quality.

Highlights of the Nazgul DC5 ECO

• 4K Ultra HD video: DJI O4 system with 1/1.3-inch sensor for stunning footage and stable 155° ultra-wide angle video.
• Robust and lightweight: High-quality carbon frame with aluminum components for a stable construction.
• Anti-Spark technology: Protects the electronics from power surges and extends the life of the XT60 connectors.
• Optimized DeadCat design: No disturbing propellers in the camera image - ideal for professional aerial photography.
• Easy maintenance: Built-in signaling devices and easily accessible components ensure convenient handling.

Product specifications

General specifications

• Product name: Nazgul DC5 ECO 6S O4 HD
• Geometry: DeadCat (DC)
• Frame: 240 mm wheelbase
• Weight: 450g ±5g (without battery)
• Take-off weight: approx. 675g ±5g (with 6S 1480mAh battery)
• Dimensions (L×W×H): 193 × 144 × 34 mm
• Max. Max.speed: 190 km/h
• Max. Hover time: approx. 7.5 minutes (6S 1480mAh, without load)
• Maximum flight altitude: 7000 m
• Wind resistance: up to level 7
• Temperature range: -10 °C to 40 °C

Flight electronics

• Flight controller: BLITZ ATF435
• ESC: BLITZ E55S 4-in-1 ESC
• Motors: XING-E Pro 2207 1800KV
• Propeller: Nazgul F5
• GPS: yes

Video transmission - DJI O4 Air Unit Pro

• Sensor: 1/1.3-inch
• Video resolution: 4K at 30fps, 1080p at 100fps
• Field of view (FOV): 155°
• Stabilization: RockSteady 3.0+
• Live-View-Qualität: 1080P@100fps
• Max. Video transmission range: up to 15 km (FCC)
• Operating frequencies: 5.170-5.850 GHz
• Built-in memory: 4GB
