GEPRC SPEEDX2 1404 3000KV FPV motor black

GEPRC SPEEDX2 1404 3000KV FPV motor black

Product description

The eye-catching red and black design gives the SPEEDX2 1404 3000KV motor an obvious high-end look. With outstanding performance and a strong anti-wear capability thanks to high-quality bearings, this motor is the ideal choice for lightweight chassis in the 2 to 4 inch range.

Features

• High quality color combination: The red and black design exudes high quality.
• High-performance bearings: Uses bearings with excellent performance and strong anti-wear capability.
• Lightweight design: The lightweight silhouette does not come at the expense of strong performance.
• Versatile application: Suitable for 2-inch to 4-inch lightweight chassis.

Specifications:

• Model: SPEEDX2 1404 3000KV motor
• Maximum power: 160W
• Peak current: 10A/3"
• Internal resistance: 0.33Ω
• Solenoid: N52H
• Bearing type: NSK/NMB
• Configuration: 9N12P
• Dimension: φ18.2mm*13.8mm
• Shaft diameter: φ1.5mm
• protruding shaft length: 4mm
• Mounting holes: 9mm*9mm（M2）
• Cable: 160mm/26AWG
• ESC: 12A/2-4S（7.4V-14.8V）
• Input voltage: 14.8V (4S LiPo)
• Winding: Copper winding with one strand
• Weight: 10.5g (including cable)
• Suitable for: 3 inch - 4 inch lightweight models
