GEPRC MK5D-LR7 HD DJI O3 Air Unit 6S Long Range Drone FPV PNP

GEPRC MK5D-LR7 HD DJI O3 Air Unit 6S Long Range Drone FPV PNP

Product description

GEPRC MK5D-LR7 HD DJI O3 Air Unit 6S Long Range Drone FPV PNP

Discover the MK5D-LR7 - the upgrade of the popular MARK5 model in 7-inch format.

The arm structure has been optimized without losing the original design style, increasing strength and improving flight error tolerance rate. Equipped with GEPRC's new compact M8U GPS, it offers you a strong guarantee for your long-range flight. The MK5D-LR7 uses the GEPRC SPAN F722-BT-HD V2 stack. The flight controller is equipped with ICM 42688P gyroscope for smooth flights, redundant power and connections, and supports Bluetooth wireless connection for parameter adjustment. With GEP-2806.5 motor and HQ Prop 7X4X3 propeller, you will get powerful performance. Thanks to the DC structure, the propellers are not in the field of view, which is ideal for O3 shooting on board.

The MK5D-LR7 comes with two different camera mounts compatible with a variety of GoPro action cameras as well as Naked GoPro 8, GoPro 10, Insta 360 GO2 and Caddx Peanut cameras to record beautiful moments during your flight.

Features

• Improved aluminum alloy side plates for more durability and visual effect.
• Built-in Bluetooth to connect wirelessly with cell phone for parameter tuning.
• Improved arm strength without losing the original style while increasing strength.
• HD version uses DJI O3 VTX for clear images, stable signal, low latency, long range and supports recording up to 4K/120fps.
• Unique frame shock absorption design for less vibration and a safe and stable operating environment for electronics.
• Separate compartment for capacitors and signal generators for an extremely stable operating environment without vibration.
• Design with two types of camera mounts compatible with a wide range of GoPro cameras as well as Naked GoPro 8, GoPro 10, Insta 360 GO2 and Caddx Peanut cameras. Stable and Clear Shooting.
• With GEP-VTC6-6000mAh battery, the flight time is 30 minutes, and with GoPro 10, the flight time is 20 minutes.

Specifications

• Model: MK5D-LR7
• Brand: GEPRC
• Frame: GEP-MK5D-LR7
• Dimensions: 230 mm × 350 mm
• Wheelbase: 335 mm
• Top plate: 2,5 mm
• Lower plate: 2,5 mm
• Arm board: 6.0 mm
• FC system: SPAN F722-BT-HD V2
• MCU: STM32F722
• ICM: 42688-P (SPI)
• OSD: BetaFlight OSD with AT7456E chip
• ESC: SPAN G50A BLHeli_32 4IN1 50A 4-6S ESC
• Propeller: HQ Prop 7X4X3 three blade propeller
• Motor: SPEEDX2 2806.5 1350KV (6S version)
• GPS: GEP-M8U
• Antenna: Momoda 5.8G LHCP UFL 175 mm x 2
• Weight: 585.0 g (MK5D-LR7 O3 version including 3D printed parts)
• Receiver versions: PNP
• https://www.fpv24.com/de/blog/62/abkurzungen
• Recommended battery: LiPo 6S 6000mAh (6S version)
