Furious FPV PikoF4 - Micro Sized, Massive Punch. Revolutionizing the FPV scene, Furious FPV pushes it to the max with the all new PikoF4 Flight Controller, featuring a no compromise design that …...
Furious FPV PikoF4 - Micro Sized, Massive Punch.
Revolutionizing the FPV scene, Furious FPV pushes it to the max with the all new PikoF4 Flight Controller, featuring a no compromise design that is ready to immerse itself into your favorite FPV machine.
Designed as a stackable unit with the feature packed INNOVA V4, the PikoF4 pushes the envelope of performance with F4 processing power that provides "on the rails" flight capability, augmented by an MPU6000 sensor package with ultra high 8kHz sampling rates. Furthermore, adding a massive 100A maximum built in PDB, the PikoF4 is designed for the extremes of ultimate FPV.
Featuring 16MB of Black Box flash memory for critical flight data breakdown, the PikoF4 is as cutting edge as it comes, featuring a built-in inverter for Smartport connection directly to the FC. Offering rich and brilliant feature when it comes to data feedback for optimal tuning & setup functionality, the PikoF4 is the tuners’ dream for on demand in-flight feedback.
Integrated with an Inrush Voltage Protection system (Input & Output) via Transient Voltage Suppressor, the PikoF4 is wickedly technical & ready for anything. Add a built in driver inverter for S-bus & integrated buzzer driver with a 5V 1A integrated BEC, the PikoF4 is the all-in-one FC solution that provides everything your quad needs in an ultra simplified design.
Step into the Furious FPV PikoF4 - potent capability coalesced with race winning functionality designed to push your FPV to the outer edges & beyond.
- F4 Processing Power
- Built In 100A Maximum PDB
- MPU6000 6 Axis Sensor Technology
- 16MB Black Box Flash Memory
- LED Driver for WS2812b Programmable LED's
- Integrated Buzzer Driver
- Built In Driver Inverter for S-bus Capability
- Integrated 5V 1A BEC w/ 2S 7.4V - 6S 22.2V LiPo Power
- Inrush Voltage Protection Input / Output via Transient Voltage Suppressor
- Stackable w/ INNOVA V4
- Stackable ESC 4in1 10A
Size: 27x27mm, mounting hole 20x20mm
Screws: M2 with dampers, M3 without dampers
Voltage Input: 2S 7.4V - 6S 22.2V LiPo Power
PDB: 100A Maximum
Processor: F4 Chip
BEC: 5V 1A
F4 Processing Power - Pushing It to the Max.
Taking a step far and above the original Piko FC, the all new PikoF4 is augmented to harness the processing power of the F4 chip for epic "on the rails" FPV flight.
Integrated 100A Maximum PDB - Power to the People.
Don't let the small size fool you. The PikoF4 pushes the big numbers with 100A PDB capability, so put your worries aside when it comes to amperage limits. The PikoF4 has it covered.
16MB Black Box Flash Memory - Stay In the Know.
Analyzing your flights is easier than ever with room to spare for massive data downloads. With the 16MB of Flash Memory available, the Black Box feature provides endless amounts of data to push the analytics of your last flight to the absolute limits.
Stackable with the INNOVA & 4in1 10A ESC - Stack em' Up.
Bring all new levels of integration & incredible levels of capability by stacking the PikoF4. This system takes full advantage of ultra capable systems like the INNOVA V4, but brings about ultra simplified builds that are clean, purposeful and ultimately powerful.
Input & Output Inrush Voltage Protection - Safety is Key.
Protecting against extreme voltage spikes, the Inrush Input & Output Voltage protection keeps everything safe, making sure transient voltage spikes do no damage when pushing the extremes.
MPU6000 Sensor Package - 6 Axis FPV Precision Awaits.
With a 3 axis gyroscope, 3 axis accelerometer in a 4x4 packaging, the MPU600 is the world's 1st 6 axis sensor the provides massive capability & precision & an ultra compact package. With ultra high 8kHz sampling rate, this incredible sensor is your key to epic FPV.
Programmable LED Driver Functionality - Light It Up.
Integrated with an LED driver for WS2812b Programmable LED's, you now have full control of LED capability, allowing you to light up the skies with a custom array of LED functionality.
